Magnetic Float Level Switch

Get a Price/Quote
MOQ : 10 Pieces

Magnetic Float Level Switch Specification

  • Response Time
  • 1 second
  • Rated Voltage
  • 230V AC / 24V DC
  • Number of Module
  • Single
  • Protection Level
  • IP65 / IP67
  • Max. Current
  • 0.5A / 1A (depending on model)
  • Finish Type
  • Polished / Matte
  • Circuit Type
  • SPST / SPDT (as per design)
  • Mechanical Life
  • 1,000,000 operations
  • Temperature Range
  • -20C to +80C
  • Automation Grade
  • Semi-Automatic / Automatic
  • Product Type
  • Magnetic Float Level Switch
  • Material
  • Stainless Steel / Polypropylene (as per model)
  • Insulation Resistance
  • 100 M at 500VDC
  • Contact Resistance
  • 100 m
  • Max. Voltage
  • 250V AC/DC
  • Operating Temperature
  • -20C to +80C
  • Stoke
  • Customizable as per application
  • Size
  • Available from 50mm to 2000mm length
  • Color
  • Metallic Grey/Blue (Head), Silver (Rod)
  • Weight
  • Approx. 250g - 700g depending on configuration
  • Mounting Type
  • Top Mount / Side Mount
  • Current Rating
  • Max. 1A
  • No Of Poles
  • Single Pole / Double Pole (as per model)
  • Wiring
  • 2-Core / 3-Core Cable
  • Output Type
  • NO / NC (Normally Open / Normally Closed)
  • Cable Entry
  • PG9 / PG13.5 / Cable Gland
  • Operating Principle
  • Magnetic Coupling
  • Pressure Rating
  • Up to 10 Bar
  • Media Compatibility
  • Water, Oil, Chemical Solutions
  • Sensitivity
  • 2 mm liquid level
  • Switch Type
  • Reed Switch
  • Float Material
  • SS316 / PP / NBR (as specified)
  • Application Areas
  • Tanks, Reservoirs, Process Industries
  • Mounting Plate Diameter
  • 50mm / 63mm / Customizable
